Lighting & Electrical Components

• Designed to maximize the performance of your compatible Gavita® fixtures.
• Simplifies lighting management with under-friendly interfaces.
• Range of models ensures the right fit for equipment needs.
• Latest generation EL3 controller compatible with Titan Controls™ Grow Room Sensors.

• Gavita E-series Interconnect Cables supply controller signals from one ballast to additional ballasts.
• Designed for daisy chain setups with Gavita Master Controllers.
• Available in 2, 5, 8, and 10-foot configurations to suit specific applications.

• High-performance top lighting designed for commercial growers.
• Ideal for those wanting to push high-PPFD cultivation.
• Suitable for experimental applications or treatments.

The Fluence VYPR 3p offers high fixture PPF up to 2,330 µmol/s and high efficacy up to 3.8 µmol/s, enabling the direct replacement of a 1,000 W HPS fixture at more than 40% energy savings.

An optional reflector kit provides a wider light pattern and uniform PPFD at plant canopy.

• Connects Gavita® EL3 Master controller to first Titan Controls® VPD Sensor or Titan Controls® Substrate Sensor.
• Products then daisy chain together after this first connection.

Lighting control at your fingertips! The Master controller EL 1 and EL2 Gen 2 are Gavita®'s entry-level systems for centrally controlling large rooms with e-series fixtures. The second generation of Master controllers features improved and expanded functionality that raises the bar including non-volatile memory, event logging, independent sunrise and sunset setting and independent light cycles on the EL2. The EL 1 has one lighting control channel and the EL2 has two lighting control channels. The EL 1 can control 500 max repeater bus fixtures and 40 max single bus fixtures without a booster. The EL2 can control 1000 max repeater bus fixtures and 80 max single bus fixtures without a booster.

The Gavita® Master Controller EL3 is the next generation in our EL controller series, designed to maximize the performance of your compatible fixtures. The EL3 enables you to set sunrise/sunset dimming, high-temperature dimming, and high-temperature shut-off for all connected fixtures. Best of all, the EL3 lets you build and program entire schedules for your growing cycles. When using a compatible Gavita or Sun System LED fixture, you will be able to view at the individual fixture level, how each one is performing.

Lighting control at your fingertips! The Master controller EL 1 and EL2 Gen 2 are Gavita®'s entry-level systems for centrally controlling large rooms with e-series fixtures. The second generation of Master controllers features improved and expanded functionality that raises the bar including non-volatile memory, event logging, independent sunrise and sunset setting and independent light cycles on the EL2. The EL 1 has one lighting control channel and the EL2 has two lighting control channels. The EL 1 can control 500 max repeater bus fixtures and 40 max single bus fixtures without a booster. The EL2 can control 1000 max repeater bus fixtures and 80 max single bus fixtures without a booster.

Replacement reflector for the Gavita® Pro line and HortiStar requires no tools to install. The medium spread of this reflector with 100° beam angle is great for tents and small rooms. This is Gavita’s most suitable reflector for single-light set ups. The 100° is designed for uniformity and deep crop penetration in 1-2 fixture configurations. Suitable for double-ended 750-1,000W HPS.

• AC/Pushlock/Male/3-Pin/M19.
• DC/Pushlock/Female/2-Pin/M19.
• DIM/Pushlock/Male/3-Pin/M12.
• Power supply only.

Fluence Wireless Flex Dimming delivers simplicity, flexibility, and cost savings to your grow operation by replacing dimming cables to each light fixture with wireless control. Wireless Flex Dimming realizes tremendous labor costs savings from reduced installation time, eliminating potential wiring errors. Simply plug a Wireless Flex Dimming Receiver into the dimming port of each Fluence light fixture, install a Wireless Flex Dimming 0-10 V adapter, and connect the 0-10 V dimming control per zone.

Wireless Flex Dimming features qualified Bluetooth mesh technology enabled by SILVAIR that is fully compatible with any 0-10 V dimmer or environmental controllers. Wireless Flex Dimming is easy to configure and enables HPS to LED retrofit growers to add precise dimming control without installing new wiring, maximizing ROI.

• 600 volt, 1,500 watt, 5kV pulse-rated porcelain mogul base sockets.
• Accommodate all mogul base bulbs in a universal position.
• Mogul cap and washer included.
• No lead.

• 600 volt, 1,500 watt, 5kV pulse-rated porcelain mogul base sockets.
• Accommodate all mogul base bulbs in a universal position.
• Mogul cap and washer included.
• With lead.

• Fastest and easiest way to secure a lamp cord to mogul sockets.
• Offer improved strain relief and mechanical structure for wire terminations.
• Extend cable flex life.
• Mogul socket and wire are not included.

This optional reflector kit for the Fluence VYPR 3p provides a wider light pattern and uniform PPFD at plant canopy.
