LED

• Designed as a direct replacement for HID fixtures, with plug-and-play installation for instant LED conversions.
• Wide, even light distribution indiscernible from HPS light throw, with better uniformity.
• Compact design fits most HPS layouts, reducing the pain when replacing hundreds at a time.
• Broad white light with enhanced blue spectrum which may intensify terpene and cannabinoid profiles.
• Dimmable down to 35% with the Gavita EL3 Master controller (sold separately).
• Delivers 2000 µmol s-1 PAR and an efficient 3.0 µmol/j.
• Premium diodes and drivers.
• Broad Range driver to accommodate a larger voltage range of 208 - 480 V.
• IP65 wet rating and ANSI/CAN/UL 8800 compliant.
• Assembled in the USA using foreign components.
• Weight: 34.5 pounds (15.65 kilograms).

• 2 LED Clone Bars per package.
• Perfect replacement for T5 fluorescent light fixture.
• 60% more efficient, running off 18 watts.
• Tested in nursery applications.
• Color temperature: 9,000° K.
• Delivers 35 µmol/s at an efficient 2.0 µmol/j.120° wide light distribution.
• 18W per strip (0.15 amps on 120V).
• Daisy chain up to 100 strips on a 20 amp circuit.
• Two strips in array per shelf.
• Easy installation with hanging clip and zip tie slot.
• IP66 wet rated; fully waterproof with water-resistant housing and connectors.
• Rated for 54,000 hours.
• Standard 5-year warranty.
• Mounting hardware and 120 V power cord included.

• Flexible mounting and easy installation.
• Market-leading efficacies and high-light output per fixture.
• Compact power supply and linear design.
• Powerful and efficient growing all year long.
• PhysioSpec™ Spectra: BROAD R4
• OUTPUT PPF (μmol/s) (400-700nm): 2,290
• OUTPUT PF (μmol/s) (400-800nm): 2,340
• Efficacy (PE) (µmol/J): 2.8
• Efficacy (PE) (µmol/J) @50% Dim: 2.9
• Dimensions (LxWxH): 46.1 x 4.2 x 3.6 in (1,170 x 107 x 91 mm)
• Weight: 11.7 lbs (5.3 kg)
• Input Voltage: 200V to 480V AC
• W AC: 825W
• Pack Type: Bulk pack
•

• Flexible mounting and easy installation.
• Market-leading efficacies and high-light output per fixture.
• Compact power supply and linear design.
• Powerful and efficient growing all year long.
• PhysioSpec™ Spectra: BROAD R4.
• OUTPUT PPF (μmol/s) 400-700nm: 1,690 | 400-800nm: 1,730
• Efficacy (PE) (µmol/J): 2.7 | @50% Dim: 2.9
• Dimensions: (LxWxH): 35.5 x 4.2 x 3.6 in (900 x 107 x 91 mm)
• Weight: 8.4 lbs (3.8 kg)
• Input Voltage: 200V to 480V AC.
• W AC: 634W

• Flexible mounting and easy installation.
• Market-leading efficacies and high-light output per fixture.
• Compact power supply and linear design.
• Powerful and efficient growing all year long.
• PhysioSpec™ Spectra: BROAD R4
• OUTPUT PPF (μmol/s) (400-700nm): 2,290
• OUTPUT PF (μmol/s) (400-800nm): 2,340
• Efficacy (PE) (µmol/J): 2.8
• Efficacy (PE) (µmol/J) @50% Dim: 2.9
• Dimensions (LxWxH): 46.1 x 4.2 x 3.6 in (1,170 x 107 x 91 mm)
• Weight: 11.7 lbs (5.3 kg)
• Input Voltage: 200V to 480V AC
• W AC: 825W
• Pack Type: Bulk pack
•

• Flexible mounting and easy installation.
• Market-leading efficacies and high-light output per fixture.
• Compact power supply and linear design.
• Powerful and efficient growing all year long.
• PhysioSpec™ Spectra: BROAD R4.
• OUTPUT PPF (μmol/s) (400-700nm): 1,690
• OUTPUT PF (μmol/s) (400-800nm): 1,730
• Efficacy (PE) (µmol/J): 2.7
• Efficacy (PE) (µmol/J) @50% Dim: 2.9
• Dimensions: (LxWxH): 35.5 x 4.2 x 3.6 in (900 x 107 x 91 mm)
• Weight: 8.4 lbs (3.8 kg)
• Input Voltage: 200V to 480V AC.
• W AC: 634W
• Pack Type: Bulk pack.

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• 4X4 and 3X4 models for improved racking size options.
• Light Output PPF: Up to 2200 μmol/s
• Efficacy: Up to 3.0 μmol/J
• Wattages: 400w, 680w, 800w
• Lifetimes: Q90 50k hrs
• Voltage Range: 208v-480v

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 1,190
• Efficacy [µmol/J]: 3.06
• Wattage: 390W
• Voltage: 120-277V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 7.9 kg [17.4 lb]
• Spectrum: R5

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 1,210
• Efficacy [µmol/J]: 3.06
• Wattage: 390W
• Voltage: 208-480V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 7.9 kg [17.4 lb]
• Spectrum: R5

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 1,450
• Efficacy [µmol/J]: 2.85
• Wattage: 500W
• Voltage: 120-277V
• Dimensions [LxWxH]: 47 x 30 x 2.36 in [119.38 x 76.2 x 5.99 cm]
• Weight: 7.9 kg [17.4 lb]
• Spectrum: R45

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 1,750
• Efficacy [µmol/J]: 2.91
• Wattage: 620W
• Voltage: 120-277V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 10.7 kg [23.5 lb]
• Spectrum: R45

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 1,790
• Efficacy [µmol/J]: 2.91
• Wattage: 620W
• Voltage: 208-480V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 10.7 kg [23.5 lb]
• Spectrum: R45

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 2,020
• Efficacy [µmol/J]: 2.87
• Wattage: 700W
• Voltage: 120-277V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 11.9 kg [26.3 lb]
• Spectrum: R45

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 2,110
• Efficacy [µmol/J]: 2.87
• Wattage: 700W
• Voltage: 208-480V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 11.9 kg [26.3 lb]
• Spectrum: R45

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 2,200
• Efficacy [µmol/J]: 2.76
• Wattage: 800W
• Voltage: 120-277V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 11.9 kg [26.3 lb]
• Spectrum: R4a

• Removable light bars for improved installation and maintenance.
• Fully sealed light bars for easier cleaning and greater resistance to the harshest environments.
• PPF Output [µmol/s]: 2,260
• Efficacy [µmol/J]: 2.76
• Wattage: 800W
• Voltage: 208-480V
• Dimensions [LxWxH]: 47 x 43 x 2.36 in [119.38 x 109.22 x 5.99 cm]
• Weight: 11.9 kg [26.3 lb]
• Spectrum: R4a

• Flexible mounting and easy installation.
• Market-leading efficacies and high-light output per fixture.
• Compact power supply and linear design.
• Powerful and efficient growing all year long.
• PhysioSpec™ Spectra: BROAD R4.
• OUTPUT PPF (μmol/s) 400-700nm: 1,690 | 400-800nm: 1,730
• Efficacy (PE) (µmol/J): 2.7 | @50% Dim: 2.9
• Dimensions: (LxWxH): 35.5 x 4.2 x 3.6 in (900 x 107 x 91 mm)
• Weight: 8.4 lbs (3.8 kg)
• Input Voltage: 120 to 277 V AC.
• W AC: 634W

The Gavita® Pro 1700e LED is a 1700 µmol s-1 fixtures with an impressive efficiency of 2.7 µmol s-1 per watt. The pro 1700e delivers broad coverage with its 8 passively cooled LED bard. The 8-bar configuration allows you to use it in low rooms, over single benches, or even in 4 x 4 ft or 5 x 5 ft tents. This powerful, full-spectrum light source is intended for full term plant growth from the vegetative stage to the higher light requiring bloom stage. Fixture is dimmable to 50% without any loss of efficiency with the use of the Master Controllers. The Gavita E-Series Led adaptor 120-277V #906151 or 367V #906150 (sold separately) is needed for each fixture when using the controller. This fixture is build with high-quality 120-277 or 347 volt Philips brand drivers. Sun Grip® light hangers are included for handing the fixture. Dimensions 44.1 in x 44.1 in x 2.1 in. 630 watts. The Gavita Pro 1700e fixtures are UL listed, IP66 wet location rated, and FCC compliant.
