Water & Aeration

• Provide consistent water distribution across the entire system.
• Spray pattern angles downward to ensure water lands on the soil, avoiding contact with the pot's wall.
• Single-sided spray stake is ideal for placement near the edge of the pot.
• Alternative option includes Netafim's 'bow-tie' double-spray pattern for different watering needs.
• Pair with the Netafim 36 inch (#Q100716) or 48 inch (#Q102478) single spray stake assembly.

• Provide consistent water distribution across the entire system.
• Spray pattern angles downward to ensure water lands on the soil, avoiding contact with the pot's wall.
• Single-sided spray stake is ideal for placement near the edge of the pot.
• Alternative option includes Netafim's 'bow-tie' double-spray pattern for different watering needs.
• Pair with the Netafim 36 inch (#Q102480) or 48 in (#Q102479) single spray stake assembly.

• Provide consistent water distribution across the entire system.
• Spray pattern angles downward to ensure water lands on the soil, avoiding contact with the pot's wall.
• 'Bow-tie' double-spray pattern.
• Pair with the Netafim 36 inch (#Q102480) or 48 in (#Q102479) single spray stake assembly.

• Connect poly distribution lines to 5 mm UV Super Flex white polyethylene feed lines.
• Thread connectors into 5 mm tubing for secure attachment.
• Use a hole punch to create a spot for the connector in your poly distribution line.
• Insert the barbed end of the connector into the punched hole for a tight fit.
• Compatible with various water delivery methods, including drip stakes, spray stakes, and button emitters.

• 1.74 psi internal check valve prevents low emitter drainage, holding back up to a 3.9-foot column of water.
• Reduces the risk of contaminants being drawn into the emitter.
• Pressure compensating design ensures consistent flow from 10.15 to 58 psi.
• Exclusive TurboNet® flow path for regulated flow and continuous self-cleaning action.
• Sharp barb allows for easy installation with no tools required.

• 1.74 psi internal check valve prevents low emitter drainage, holding back up to a 3.9-foot column of water.
• Reduces the risk of contaminants being drawn into the emitter.
• Pressure compensating design ensures consistent flow from 10.15 to 58 psi.
• Exclusive TurboNet® flow path for regulated flow and continuous self-cleaning action.
• Sharp barb allows for easy installation with no tools required.

• 1.74 psi internal check valve prevents low emitter drainage, holding back up to a 3.9-foot column of water.
• Reduces the risk of contaminants being drawn into the emitter.
• Pressure compensating design ensures consistent flow from 10.15 to 58 psi.
• Exclusive TurboNet® flow path for regulated flow and continuous self-cleaning action.
• Sharp barb allows for easy installation with no tools required.

• Unique design regulates flow and provides continuous self-cleaning action.
• Features a 2.2 PSI internal check valve that prevents low emitter drainage, holding back up to a 5-foot column of water.
• Anti-siphon operation prevents contaminants from entering the emitter.
• Pressure compensating, ensuring consistent flow from 14.5 to 58 PSI.
• Recommended minimum filtration of 120 mesh.
• Compatible with 36" or 48" 2-way (#Q102463 / #Q102464) or 4-way (#Q112852 / #Q112853) Dripper Stake Assemblies.

• Unique design regulates flow and provides continuous self-cleaning action.
• Features a 2.2 PSI internal check valve that prevents low emitter drainage, holding back up to a 5-foot column of water.
• Anti-siphon operation prevents contaminants from entering the emitter.
• Pressure compensating, ensuring consistent flow from 14.5 to 58 PSI.
• Recommended minimum filtration of 120 mesh.
• Compatible with 36" or 48" 2-way (#Q102463 / #Q102464) or 4-way (#Q112852 / #Q112853) Dripper Stake Assemblies.

• Unique design regulates flow and provides continuous self-cleaning action.
• Features a 2.2 PSI internal check valve that prevents low emitter drainage, holding back up to a 5-foot column of water.
• Anti-siphon operation prevents contaminants from entering the emitter.
• Pressure compensating, ensuring consistent flow from 14.5 to 58 PSI.
• Recommended minimum filtration of 120 mesh.
• Compatible with 36" or 48" 2-way (#Q102463 / #Q102464) or 4-way (#Q112852 / #Q112853) Dripper Stake Assemblies.

• Multi-Outlet Dripper (MOD) supports multiple drip stake assemblies from a single drip emitter.
• Preassembled with a two-way flat manifold, two 36 - or 48-inch UV Polyethylene Tubing leads, and two 6 3/8-inch standard Angle Arrow Drippers.
• Compatible with the Netafim 1 GPH (Q112854) or 2 GPH (Q102461) Techflow Emitters.

• Multi-Outlet Dripper (MOD) supports multiple drip stake assemblies from a single drip emitter.
• Preassembled with a two-way flat manifold, two 36-inch UV Polyethylene Tubing leads, and two 6 3/8-inch standard Angle Arrow Drippers.
• Compatible with the Netafim 1 GPH (Q112854) or 2 GPH (Q102461) Techflow Emitters.

• Multi-Outlet Dripper (MOD) supports multiple drip stake assemblies from a single drip emitter.
• Preassembled with a two-way flat manifold, two 48-inch UV Polyethylene Tubing leads, and two 6 3/8-inch standard Angle Arrow Drippers.
• Compatible with the Netafim 1 GPH (Q112854) or 2 GPH (Q102461) Techflow Emitters.

• Simple to operate and maintain.
• Reliable even in harsh conditions.
• Tight sealing valve with fully supported diaphragm.
• Flow range: 0.25 - 110 GPM

• Features crisscrossed grooves in disc rings for effective debris trapping.
• As pressure increases, disc rings compress tightly, forcing water through the grooves.
• Debris is trapped within the disc rings, ensuring only clean water flows into the irrigation system.
• Operates efficiently with flow rates from 10 to 52 GPM.

• The only 1-inch regulator in the industry rated from 0.5 to 35 GPM.
• Constructed with high-strength ABS and stainless steel springs for long-lasting durability.
• Features a rolling diaphragm and sealed regulating chamber for consistent performance.
• Suitable for various applications in any irrigation system.
• Operating inlet pressure range: 30 to 150 PSI.

• The only 1-inch regulator in the industry rated from 0.5 to 35 GPM.
• Constructed with high-strength ABS and stainless steel springs for long-lasting durability.
• Features a rolling diaphragm and sealed regulating chamber for consistent performance.
• Suitable for various applications in any irrigation system.

• The only 1-inch regulator in the industry rated from 0.5 to 35 GPM.
• Constructed with high-strength ABS and stainless steel springs for long-lasting durability.
• Features a rolling diaphragm and sealed regulating chamber for consistent performance.
• Suitable for various applications in any irrigation system.

The Netafim™ Punch Tool is a heavy duty plastic handle punch that makes adding any Netafim drippers to your irrigation system easy and convenient.

Did you goof? Use the Netafim™ Goof Plug to repair dripper holes that were accidentally punched in error.

• Equipped with a barbed outlet and CNL check valve to prevent low emitter drainage.
• Anti-siphon operation keeps contaminants from entering the emitter.
• Pressure compensating design ensures consistent flow from 12 - 58 PSI.
• Compatible with Netafim Super Flex UV White PE Tubing (#Q100705).

• Equipped with a barbed outlet and CNL check valve to prevent low emitter drainage.
• Anti-siphon operation keeps contaminants from entering the emitter.
• Pressure compensating design ensures consistent flow from 12 - 58 PSI.
• Compatible with Netafim Super Flex UV White PE Tubing (#Q100705).

• Equipped with a barbed outlet and CNL check valve to prevent low emitter drainage.
• Anti-siphon operation keeps contaminants from entering the emitter.
• Pressure compensating design ensures consistent flow from 12 - 58 PSI.
• Compatible with Netafim Super Flex UV White PE Tubing (#Q100705).

• Equipped with a barbed outlet and CNL check valve to prevent low emitter drainage.
• Anti-siphon operation keeps contaminants from entering the emitter.
• Pressure compensating design ensures consistent flow from 12 - 58 PSI.
• Compatible with Netafim Super Flex UV White PE Tubing (#Q100705).

• Equipped with a barbed outlet and CNL check valve to prevent low emitter drainage.
• Anti-siphon operation keeps contaminants from entering the emitter.
• Pressure compensating design ensures consistent flow from 12 - 58 PSI.
• Compatible with Netafim Super Flex UV White PE Tubing (#Q100705).
