Products tagged with 'Irrigation Fittings'

The unique design of the Netafim Techflow Emitters regulates flow and provides continuous self-cleaning action during operation. These emitters have a 2.2 PSI internal check valve that helps prevent low emitter drainage holding back up to a 5 ft column of water. The anti-siphon operation prevents contaminants from being drawn into the emitter. The Techflow Emitters are pressure compensating and deliver the same flow from 14.5 to 58 PSI. Recommended minimum filtration of 120 mesh. Pair the Techfl

The Netafim Multi-Outlet Dripper assembly allows you to operate multiple drip stake assemblies from one drip emitter. The MOD comes preassembled with a 2-way flat manifold two 36 in UV Polyethylene Tubing leads and two 6 3/8 in standard Angle Arrow Drippers. Pair the MOD with the Netafim 1 GPH (HGC747708) or 2 GPH (HGC747746) Techflow Emitters.

"""The Netafim Wide Range Pressure Regulator is the only 1"""" regulator in the industry that is rated from 0.5 to 35 GPM. High strength ABS construction and stainless steel springs provide long-life and can be used in a variety of applications while the rolling diaphragm and sealed regulating chamber provide consistent high quality performance in any irrigation system. Operating inlet pressure range: 30 to 150 PSI."""

The Netafim Woodpecker Junior Drippers have a barbed outlet and CNL check valve that helps prevent low emitter drainage. The anti-siphon operation prevents contaminants from being drawn into the emitter. These Woodpecker Drippers are pressure compensating and deliver the same flow from 12 - 58 PSI. The barbed outlet fits the Netafim Super Flex UV White PE Tubing (HGC747561).

The Netafim Medium Flow Pressure Regulator will instantly respond to variations in pressure assuring the 35 PSI outlet pressure will remain constant regardless of inlet pressure. Non-corrosive high quality plastic bodies withstand commonly used fertilizers and chemicals. This sealed regulating unit uses a stainless steel spring and screw that are field replaceable and easy to maintain. Maximum Operating Pressure: 145 PSI.

Netafim single dripper stake assemblies will reduce setup time considerably. This 36 or 48 inch assembly will install right where you need it. Dripper assembly uses a 3.2 or 6.6 GPH pressure compensating emitter with CNL check valve 36 or 48 inches of Super Flex Tubing. Minimum operating pressure is 22 PSI. Pair the 3.2 GPH assemblies with the Netafim single pattern standard spray stakes (HGC747735) and the 6.6 GPH assemblies with the Netafim single pattern (HGC747736) or double pattern (HGC747
