Lighting

Replacement reflector for the Gavita® Pro line and HortiStar requires no tools to install. The medium spread of this reflector with 100° beam angle is great for tents and small rooms. This is Gavita’s most suitable reflector for single-light set ups. The 100° is designed for uniformity and deep crop penetration in 1-2 fixture configurations. Suitable for double-ended 750-1,000W HPS.

Gavita® horticultural High Pressure Sodium (HPS) lamp with high output and extreme long light maintenance. Change once a year for best results. Light maintenance 5,000 hrs: >96%. Color temperature is 2,100° K and the lamp base is K12 x 30s. Suitable for High Frequency Gavita ballasts. The jacket of this double-ended lamp is made from quartz glass. Do not handle with bare hands. Oil from your hands can damage the lamp.

The Gavita® Pro 1700e LED is a 1700 µmol s-1 fixtures with an impressive efficiency of 2.7 µmol s-1 per watt. The pro 1700e delivers broad coverage with its 8 passively cooled LED bard. The 8-bar configuration allows you to use it in low rooms, over single benches, or even in 4 x 4 ft or 5 x 5 ft tents. This powerful, full-spectrum light source is intended for full term plant growth from the vegetative stage to the higher light requiring bloom stage. Fixture is dimmable to 50% without any loss of efficiency with the use of the Master Controllers. The Gavita E-Series Led adaptor 120-277V #906151 or 367V #906150 (sold separately) is needed for each fixture when using the controller. This fixture is build with high-quality 120-277 or 347 volt Philips brand drivers. Sun Grip® light hangers are included for handing the fixture. Dimensions 44.1 in x 44.1 in x 2.1 in. 630 watts. The Gavita Pro 1700e fixtures are UL listed, IP66 wet location rated, and FCC compliant.

Lighting control at your fingertips! The Master controller EL 1 and EL2 Gen 2 are Gavita®'s entry-level systems for centrally controlling large rooms with e-series fixtures. The second generation of Master controllers features improved and expanded functionality that raises the bar including non-volatile memory, event logging, independent sunrise and sunset setting and independent light cycles on the EL2. The EL 1 has one lighting control channel and the EL2 has two lighting control channels. The EL 1 can control 500 max repeater bus fixtures and 40 max single bus fixtures without a booster. The EL2 can control 1000 max repeater bus fixtures and 80 max single bus fixtures without a booster.

The Gavita® Master Controller EL3 is the next generation in our EL controller series, designed to maximize the performance of your compatible fixtures. The EL3 enables you to set sunrise/sunset dimming, high-temperature dimming, and high-temperature shut-off for all connected fixtures. Best of all, the EL3 lets you build and program entire schedules for your growing cycles. When using a compatible Gavita or Sun System LED fixture, you will be able to view at the individual fixture level, how each one is performing.

• Connects Gavita LED fixtures together.
• 10-foot (3-meter) RJ45-to-RJ45 signal cable.

• Connects Gavita® EL1 or EL2 controllers to the first Gavita LED fixture.
• 25-foot (7.5-meter) RJ45-to-RJ9 signal cable.

• Designed to be used with Gavita 1700e LED fixtures.
• Branches the signal into dual output paths.
• For cables with RJ45 connectors.

• Eight-foot (2.4 meter) power cord for Gavita® LED fixtures.
• 120-volt plug to 5-pin Wieland connection.

• The Gavita® CT 1930e is the first LED to directly replace HPS.
• Fits seamlessly into existing HPS layouts.
• Highly energy-efficient delivering serious growing power.
• Designed as a 1:1 layout replacement for the Gavita Pro 1000e DE HPS.
• Compatible with wiring and electrical requirements for most indoor growing environments.
• Limits the cost and downtime required to convert facilities of every size.
• Delivers more light in a broader spectrum with up to 20% energy savings compared to Gavita 1000 W DE and single-ended HPS fixtures.*
• Compatible with Gavita EL Master Controllers (sold separately) and most building automation systems.
• Embedded controller technology enables control of up to 2,000 fixtures per EL Master control channel.
• Voltage: 120-277 V.

*based on average wattage of each fixture.

• The Gavita® CT 1930e is the first LED to directly replace HPS.
• Fits seamlessly into existing HPS layouts.
• Highly energy-efficient delivering serious growing power.
• Designed as a 1:1 layout replacement for the Gavita Pro 1000e DE HPS.
• Compatible with wiring and electrical requirements for most indoor growing environments.
• Limits the cost and downtime required to convert facilities of every size.
• Delivers more light in a broader spectrum with up to 20% energy savings compared to Gavita 1000 W DE and single-ended HPS fixtures.*
• Compatible with Gavita EL Master Controllers (sold separately) and most building automation systems.
• Embedded controller technology enables control of up to 2,000 fixtures per EL Master control channel.
• Voltage: 277-480 V.

*based on average wattage of each fixture.

• One of the best 1,000 watt HPS lamps on the market.
• It is specifically designed for high frequency electronic ballasts.
• Connection at each end of the lamp removes need for a frame wire inside.
• Lamp jacket is made from quartz glass.
• For use with Gavita fixtures only.

• Used to operate one or more Gavita® CT 1930e light fixtures without the use of a lighting controller.
• Ensures continuous operation at 100% output* when placed on the input of the first fixture.

• Connects Gavita® EL3 Master controller to first Titan Controls® VPD Sensor or Titan Controls® Substrate Sensor.
• Products then daisy chain together after this first connection.

• Extremely efficient low-heat horticultural lighting system.
• T5 Super High Output (SHO) lighting provides an ideal spectrum for plant growth.
• Minimal heat output allows placement 6 to 8 in (15.24 to 20.32 cm) above plant canopy.
• No risk of scorching leaves, unlike MH lighting.
• Closer placement maximizes photosynthetic response and promotes fuller growth at lower wattage.
• Includes T5 SHO grow bulbs, built-in ballast, hanging hardware, and 12-foot (3.7-meter) grounded power cord.
• Two-year rebuild or replace warranty.
• ETL approved.
• Dimensions (L x W x H): 4 ft x 9 in x 3 in (122 x 23 x 7.6 cm).

• Extremely efficient low-heat horticultural lighting system.
• T5 Super High Output (SHO) lighting provides an ideal spectrum for plant growth.
• Minimal heat output allows placement 6 to 8 in (15.24 to 20.32 cm) above plant canopy.
• No risk of scorching leaves, unlike MH lighting.
• Closer placement maximizes photosynthetic response and promotes fuller growth at lower wattage.
• Includes T5 SHO grow bulbs, built-in ballast, hanging hardware, and 12-foot (3.7-meter) grounded power cord.
• Two-year rebuild or replace warranty.
• ETL approved.
• Dimensions (L x W x H): 2 ft x 14.5 in x 3 in (60 x 37 x 7.6 cm).

• 1,000 watt magnetic ballast.
• Can easily switch between MH and HPS bulbs by flipping a specialized switch.
• Can also be switched between four primary input voltages: 120 V, 208 V, 240 V or 277 V.
• The aluminum housing is specially designed to dissipate heat and keep components cool.
• Top of the line Aerovox® capacitor is also included.
• Use the 120 V or 240 V power cord (sold separately) to change between these two voltages.
• If 208 V or 277 V operation is required the wiring must be changed by a certified electrician.
• The lamp cord receptacle accepts all LightEnerG™ lamp cords and reflectors.
• UL approved.

• Extremely efficient low-heat horticultural lighting system.
• T5 Super High Output (SHO) lighting provides an ideal spectrum for plant growth.
• Minimal heat output allows placement 6 to 8 in (15.24 to 20.32 cm) above plant canopy.
• No risk of scorching leaves, unlike MH lighting.
• Closer placement maximizes photosynthetic response and promotes fuller growth at lower wattage.
• Includes T5 SHO grow bulbs, built-in ballast, hanging hardware, and 12-foot (3.7-meter) grounded power cord.
• Two-year rebuild or replace warranty.
• ETL approved.
• Dimensions (L x W x H): 46.2 x 34 x 2.95 in (117 x 86 x 7.5 cm).

• Extremely efficient low-heat horticultural lighting system.
• T5 Super High Output (SHO) lighting provides an ideal spectrum for plant growth.
• Minimal heat output allows placement 6 to 8 in (15.24 to 20.32 cm) above plant canopy.
• No risk of scorching leaves, unlike MH lighting.
• Closer placement maximizes photosynthetic response and promotes fuller growth at lower wattage.
• Includes T5 SHO grow bulbs, built-in ballast, hanging hardware, and 12-foot (3.7-meter) grounded power cord.
• Two-year rebuild or replace warranty.
• ETL approved.
• Dimensions (L x W x H): 2 ft x 9 in x 3 in (60 x 23 x 7.6 cm).

• 1,000 watt magnetic ballast.
• Can easily switch between MH and HPS bulbs by flipping a specialized switch.
• Also switchable between 120 V and 240 V.
• Use provided 120 V cord or 240 V cord (sold separately).
• No additional wiring is necessary.
• The aluminum housing dissipates heat and keeps components cool.
• Includes a top-of-the-line Aerovox® capacitor.
• Lamp cord receptacle accepts all LightEnerG lamp cords and reflectors.

• Magnetic ballast capable of switching between 120 V and 240 V.
• Use either the 120v or a 240v power cord (sold separately) to change the voltage of the ballast.
• No additional wiring is necessary.
• Can also be used with 600 W MH conversion lamps.
• Aluminum housing is specially designed to dissipate heat and keep components cool.
• Includes a top-of-the-line Aerovox® capacitor.
• Lamp cord receptacle accepts all LightEnerG lamp cords and reflectors.

• 400 watt magnetic ballast.
• Can easily switch between MH and HPS bulbs by flipping a specialized switch.
• Also switchable between 120 V and 240 V.
• Use provided 120 V cord or 240 V cord (sold separately).
• No additional wiring is necessary.
• The aluminum housing dissipates heat and keeps components cool.
• Includes a top-of-the-line Aerovox® capacitor.
• Lamp cord receptacle accepts all LightEnerG lamp cords and reflectors.
